CKO turbine flowmeter
Technical parameter
Nominal diameter: 40mm ~ 250mm
Accuracy class: ±1%
Output signal: 4 ~ 20mA
Power supply: 24V
Measured media: natural gas, coal-to-gas, air, liquid, etc...
Technical parameter
Nominal diameter: 40mm ~ 250mm
Accuracy class: ±1%
Output signal: 4 ~ 20mA
Power supply: 24V
Measured media: natural gas, coal-to-gas, air, liquid, etc...
CK0 intelligent liquid turbine flowmeter has the characteristics of simple structure, light weight, high precision, good repeatability, sensitive response, easy installation, maintenance and use. It is widely used to measure the liquid with stainless steel 1Cr18NiTi, 2Cr12 and corundum A1203 in closed pipelines, which is non-corrosive, and has no impurities such as fibers and particles, and the kinemtic viscosity is less than 5X10-6m/s at working temperature. For liquids with kinematic viscosity greater than 5X10-6m/s, the flowmeter can be used after solid liquid calibration. If it is matched with a display instrument with special functions, it can also carry out quantitative control and overdosage alarm.
